產品中心products

HZT系列化工通道泵 / HZT Series

HZT系列化工通道泵性能參數表(3)

發布時間:2019-10-26 瀏覽次數：2278

型號	轉速 r/min	流量 m3/h	揚程 m	額定流量 m3/h	額定揚程 m	效率	軸功率 kw	配用電機			汽蝕余量
型號	轉速 r/min	流量 m3/h	揚程 m	額定流量 m3/h	額定揚程 m	效率	軸功率 kw	比重γ=1.00	比重γ=1.35	比重γ=1.84	汽蝕余量
80-50-300	1450	16-24	16-26	20	25	45	3	Y112M-4/4	Y132S-4/5.5	Y132M-4/7.5	3.8
80-50-300	2900	32-48	65-103	40	100	50	21.8	Y180M-2/22	Y200L1-2/30	Y225M-2/45	3.8
80-50-315	1450	20-30	29-35	25	32	56	3.9	Y132S-4/5.5	Y132S-4/5.5	Y160M-4/11	2
80-50-315	2900	40-60	100-127	50	125	51	33.36	Y200L2-2/37	Y250M-2/55	Y280S-2/75
80-50-315A		37-56	86-125	46.5	108	51	26.8	Y200L1-2/30	Y200L2-2/37	Y250M-2/55
80-50-315B		35-52	76-100	43.5	94.5	50	22.4	Y200L1-2/30	Y200L2-2/37	Y250M-2/55
80-50-400	1450	16-24	31-49	20	47.5	29	8.9	Y160M-4/11	Y160L-4/15	Y180M-4/18.5	4.5
80-50-400	2900	32-48	123-1985	40	190	34	60.9	Y280S-2/75	Y280M-2/90	Y315M1-2/132	4.5
100-80-125	1450	40-60	4-6	50	5	69	1	Y90L-4/15	Y90L-4/1.5	Y100L1-4/2.2	2
100-80-125	2900	68-120	16-24	100	20	74	7.36	Y160M1-2/11	Y160M1-2/11	Y160M2-2/15	4.3
100-80-250A		65-112	14-22	93	17.3	73	6	Y132S2-2/7.5	Y160M1-2/11	Y160M2-2/15
100-80-125B		69.6-104	12-18	87	15.1	72.5	4.9	Y132S1-2/5.5	Y132S2-2/7.5	Y160M1-2/11
100-80-160	1450	40-60	6.4-9	50	8	69	1.58	Y100L1-4/2.2	Y100L2-4/3	Y112M-4/4	3.4
100-80-160	2900	70-120	26-35	100	32	73	11.9	Y160M2-2/15	Y160L2-2/18.5	Y180M-2/22	2.5
100-80-60A	2900	65-110	25-32	93	28	69	10.3	Y160M1-2/11	Y160M2-2/15	Y160L-2/18.5	2.5
100-80-200	1450	60-90	10-15	75	12.5	68	3.75	Y112M-4/4	Y132S-4/5.5	Y132M-4/7.5	6.5
100-80-200	2900	120-170	38-54	150	50	73	27.97	Y200L1-2/30	Y225M-2/45	Y250M-2/55
10-80-200A	2900	108-162	33-50	135	41.5	69	22.1	Y200L1-2/30	Y200L1-2/30	Y225M-2/45
100-65-180	1450	30-45	6.5-11	37.5	10	65	1.57	Y100L1-4/2.2	Y100L1-4/2.2	Y100L2-4/3	3.5
100-65-180		56-90	Apr-36	75	40	70	11.68	Y160M2-2/15	Y160L-2/18.5	Y180M-2/22	3.5
100-65-200	1450	40-60	10-15	50	12.5	68	2.5	Y100L2-4/3	Y112M-4/4	Y132S-4/5.5	3.9
100-65-200	2900	80-120	45-53	100	50	72	18.9	Y180M-2/22	Y200L1-2/30	Y225M-2/45
100-65-200A	2900	64-120	35-46	93	43	71	15.3	Y160L-2/18.5	Y180M-2/22	Y200L1-2/30
100-65-220	1450	30-45	11-17	37.5	16	60.5	2.7	Y100L2-4/3	Y112M-4/4	Y132S-4/5.5	3.5
100-65-220	2900	56-90	42-67	75	65	65.5	20.3	Y180M-2/22	Y200L1-2/30	Y225M-2/45	3.5
100-65-250	1450	40-60	16-22	50	20	63	4.3	Y132S-4/5.5	Y132M-4/7.5	Y160M-4/11	3.6
100-65-250	2900	70-130	70-84	100	80	65	33.5	Y200L2-2/37	Y225M-2/45	Y280S-2/75
100-65-250A		65-120	60-74	93	69	65	26.8	Y200L1-2/30	Y200L2-2/37	Y250M-2/55
100-65-250B		70-105	49-72	87	60.5	65	22.1	Y200L1-2/30	Y200L1-2/30	Y225M-2/45
100-65-300	1450	30-45	16-26	37.5	25	55.5	4.6	Y132S-4/5.5	Y132M-4/7.5	Y160M-4/11	4
100-65-300	2900	56-90	65-103	75	100	60.5	33.8	Y200L2-2/37	Y250M-2/55	Y280S-2/75	4
100-65-315	1450	35-65	30-33	50	32	60	7.26	Y160M-4/11	Y160M-4/11	Y160L-4/15	2
100-65-315	2900	80-120	115-127	100	125	62	54.9	Y250M-2/55	Y280S-2/75	Y315S-2/110	3.6
100-65-315A		65-110	86-125	93	108	62	44.1	Y250M-2/55	Y280S-2/75	Y280M-2/90
100-65-315B		70-105	76-114	87	95	62	36.3	Y225M-2/45	Y250M-2/55	Y280S-2/75
100-65-315C		70-108	81-121	90	101	62	39.9	Y225M-2/45	Y250M-2/55	Y280S-2/75
100-65-400	1450	30-45	31-49	37.5	47.5	40	12.13	Y160L-4/15	Y180M-4/18.5	Y180L-4/22	5
100-65-400	2900	56-90	123-195	75	190	45	86.3	H280M-2/90	Y315M1-2/132	Y315M2-2/160	5
100-80-400	1450	60-90	45-53	75	50	52	19.65	Y180L-4/22	Y200L-4/30	Y225S-4/37
100-80-400	2900	120-70	180-202	150	200	55.5	147.3	Y315M2-2/160	Y315L2-2/200	Y355L1-2/280
100-80-200	1450	60-90	10-15	75	12.5	65	3.75	Y112M-4/4	Y132S-4/5.5	Y132M-4/7.5	6.5
100-80-200	2900	100-180	40-60	150	50	70	29.2	Y200L1-2/30	Y225M-2/45	Y250M-2/55
125-80-200A	2900	95-170	38-46	135	41.5	70	21.8	Y200L1-2/30	Y200L1-2/30	Y225M-2/45
